| Brand | Hikvision | |
| Gamma | Value | |
| Image Sensor | 3K CMOS | |
| Maximum resolution | 3K (2960x1665) at 20 fps | |
| Resolution | TVI: 3K (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps) CVI: 4Mpx (25~30 fps) AHD: 5Mpx (20 fps), 4Mpx (25~30 fps) CVBS: PAL/NTSC >Angle of view (FOV) | 107º (H), 64º (V), 129º (D) |
| Minimum illumination | Color: 0.01 Lux @ (F1.2, AGC ON) Black and white: 0 lux with IR | |
| Infrared lighting | Dual light: Smart IR Range 30 m White light range 20 m | |
| Day / Night | Auto / Color / Black and White (ICR) | |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS | |
| Switching output video | Via Switch | |
| Basic functions | OSD menu (remote) | |
| Configurable OSD functions | DWDR, AGC, AWB, Smart IR | |
| Communication | HIKVISION-C | |
| Audio | Built-in microphone (audio via coaxial cable in technology TVI) | |
| Lens Positioning | 3 Axis | |
| Power | DC 12 V / 2.9 W max. | |
| Protection degree | Waterproof IP67 | |
| Temp. operation | -40º C ~ +60º C | |
| Material | Metal | |
| Dimensions | Ø 85.1 mm x 80mm (Al) | |
| Base diameter | Ø base 85.1 mm / Ø between screws 60 mm / 3 screws | |
| Weight | 300 g |
