Hikvision 24-inch Full HD 100 Hz CCTV Monitor DS-D5024F2-AP2
- 24" Monitor
- FHD Resolution
- Refresh Rate 60 / 100 Hz
- Contrast 1000:1
- Response Time 14 ms
Description & Key Features: DS-D5024F2-AP2
The DS-D5024F2-AP2 is a specialized CCTV monitor designed for continuous operation in security environments. Unlike conventional monitors, it provides clear and detailed video playback, making it ideal for real-time surveillance in various settings such as commercial buildings, banks, airports, and homes. With its compatibility with security systems through HDMI, VGA, and BNC inputs, this monitor is essential for effective video monitoring and recording systems.
CCTV monitors are optimized for long-term use, ensuring reliability and performance. They often include technologies that enhance visibility in low-light conditions, which is crucial for detecting details in security footage.
- 24" Monitor
- FHD Resolution
- Brightness 250 cd/m2
- Contrast 1000:1
- Response Time 14 ms
- 24/7 Operation
- VESA 75x75 mm
Specifications: DS-D5024F2-AP2
| Brand | Hikvision |
| Size | 23.8" |
| Resolution | 1920x1080 |
| Refresh Rate | 60 / 100 Hz |
| Aspect Ratio | 16:9 |
| Brightness | 250 cd/m2 |
| Contrast | 1000:1 |
| Response Time | 14 ms |
| Viewing Angle (Horizontal / Vertical) | 178º / 178º |
| Color Depth | 8 bits, 16.7 M |
| Color Gamut | 72% NTSC |
| Operation | 24/7 |
| Inputs | HDMI x1 VGA x1 |
| Outputs | Audio 3.5mm x1 |
| VESA | 75x75 mm |
| Average Power Consumption | <25 W |
| Power Supply | DC 12V, 2.0A |
| Dimensions | Without stand: 539.7 (W) × 327.33 (H) × 43.5 (D) mm With stand: 539.7 (W) × 427.33 (H) × 185.69 (D) mm |
| Weight | 3.5 Kg |
| Operating Conditions | Temperature: 0 ~ 40 ºC Humidity (non-condensing): 20 ~ 90 % |
| Storage Conditions | Temperature: -20 ~ 60 ºC Humidity (non-condensing): 10 ~ 90 % |
Package Contents
- Monitor
- Power Adapter
- HDMI Cable
- Stand
- User Manual
- Quick Start Guide
Use Case
The DS-D5024F2-AP2 monitor is an excellent choice for security professionals looking to enhance their surveillance systems. In a typical deployment scenario, this monitor can be installed in a control room of a commercial building, where it will display live feeds from multiple CCTV cameras. The monitor's FHD resolution ensures that security personnel can easily identify details, while its 24/7 operation capability allows for uninterrupted monitoring. Additionally, the monitor's compatibility with various input types, such as HDMI and VGA, makes it versatile for different setups. The low response time of 14 ms ensures that there is minimal lag in video playback, which is crucial for real-time decision-making. Overall, the DS-D5024F2-AP2 is a reliable solution for any security installation, providing clarity and performance in critical situations.
Data sheet
- Brand
- HIKVISION
- Compatible models
- TVM-1327DESK-FLEX-PCDUAL,TVM-1327DESK-FLEX-PCDUAL,TVM-1327DESK-FLEX-PCDUAL,TVM-1327DESK-FLEX-DUAL,TVM-1327DESK-FLEX-DUAL,TVM-1327DESK-FLEX,TVM-1327DESK-FLEX,STB-111-01,STB-111-01,LDT66-T024,LDT66-T024,LDT66-C02V,LDT66-C02V,LDT66-C024ML,LDT66-C024ML,LDT66-
Specific References
- EAN13
- 6942160487304
