Hikvision 55-inch FHD CCTV Monitor 24-Hour Operation DS-D2055UL-1B
- 55" video wall monitor
- FHD resolution
- 500 nits brightness
- 3.5 mm bezel (A-A)
- 24/7 operation
- Horizontal orientation
Description & Key Features: DS-D2055UL-1B
The DS-D2055UL-1B is a 55-inch video wall monitor designed to create a large, high-resolution display by combining multiple screens. This device is ideal for environments that require the visualization of information on a grand scale, such as control centers, conference rooms, airports, train stations, and live events. With its ability to present content in full-screen or multiple individual displays, it offers exceptional flexibility in data presentation. The monitor is perfect for applications demanding high visibility, making it a top choice for electronic security and surveillance systems.
Video wall monitors are electronic screens that, when combined, form a single larger display with enhanced resolution, allowing for the presentation of content in various formats. They are particularly suited for applications that require high visibility and flexibility in presenting data, graphics, or videos, as they can be configured in different sizes and resolutions based on the environment's needs.
- Video wall monitor 55"
- FHD resolution
- Brightness 500 nits
- Bezel 3.5 mm (A-A)
- Horizontal orientation
- 24/7 operation
Specifications: DS-D2055UL-1B
| Brand | HIKVISION |
| Size | 55" |
| Resolution | 1920x1080 |
| Refresh Rate | 60 Hz |
| Bezel | 3.5 mm (A-A: total bezel when installing two monitors together) |
| Brightness | 500 nits |
| Contrast | 1200:1 |
| Anti-glare (haze) | 25% |
| Response Time | 7.5 ms |
| Viewing Angle (horizontal / vertical) | 178º / 178º |
| Color Depth | 8 bit (16.7 M) |
| Color Gamut | 72% NTSC |
| Operation | 24/7 |
| Inputs | HDMI x1 DP x1 DVI x1 VGA x1 USB x1 RS232 (control) x1 |
| Outputs | HDMI x1 RS232 (control) x1 |
| Daisy Chain | Yes, via HDMI |
| Orientation | Horizontal |
| Dimensions | 1,213.5 (W) × 684.5 (H) × 71.19 (D) mm |
| VESA | 600x400 mm |
| Weight | 19.8 Kg |
| Power Supply | AC 100 ~ 240 V 50/60 Hz |
| Power Consumption | <=245 W (max.) |
| Operating Conditions | Temperature 0 ~ 40 ºC Humidity (non-condensing) 10 ~ 80 % |
| Storage Conditions | Temperature -20 ~ 60 ºC Humidity (non-condensing) 10 ~ 90% |
Package Contents
- Video Wall Monitor
- Power Cable
- Ethernet Cable
- HDMI Cable (2 m)
- Mounting Hardware
- Remote Control
- Quick Start Guide
Use Case
The DS-D2055UL-1B video wall monitor is an excellent choice for a variety of deployment scenarios, particularly in high-traffic areas such as airports and control rooms. For instance, in an airport terminal, multiple monitors can be configured in a daisy chain setup to display flight information, advertisements, and security alerts simultaneously. This configuration not only enhances the visibility of critical information but also allows for seamless updates in real-time. The monitor's 24/7 operation capability ensures that it can handle continuous use without downtime, making it reliable for environments that require constant monitoring. Additionally, the FHD resolution and 500 nits brightness provide clear and vibrant visuals, essential for capturing the attention of travelers. The flexibility in orientation and the slim bezel design further enhance the aesthetic appeal, making it suitable for modern installations.
Data sheet
- Brand
- HIKVISION
- Compatible models
- DS-DN4655W/U-T1
Specific References
- EAN13
- 6942160479927
