Hikvision 43-inch Full HD 60 Hz CCTV Monitor DS-D5043F3-1V0S
- 43" Monitor
- FHD Resolution
- 60 Hz Refresh Rate
- 4000:1 Contrast
- 6.5 ms Response Time
- 2x10 W Speakers
Description & Key Features: DS-D5043F3-1V0S
The DS-D5043F3-1V0S is a specialized CCTV monitor designed for continuous operation in various security environments. It excels in providing clear and detailed video playback, making it ideal for use in commercial buildings, banks, airports, and homes. This monitor supports multiple video inputs, including HDMI, VGA, and BNC, ensuring compatibility with various security systems. Its advanced features enhance visibility in low-light conditions, making it a vital component for effective surveillance.
CCTV monitors, unlike conventional monitors, are optimized for long-term use, offering superior video reproduction. They are essential for real-time monitoring of images captured by security cameras and play a crucial role in reviewing footage stored in DVRs (Digital Video Recorders) or NVRs (Network Video Recorders).
- 43" Monitor
- FHD Resolution
- Brightness 300 cd/m2
- Contrast 4000:1
- Response Time 6.5 ms
- 24/7 Operation
- VESA 200x200 mm
- Integrated Speakers
Specifications: DS-D5043F3-1V0S
| Brand | Hikvision |
| Size | 43" |
| Resolution | 1920x1080 |
| Refresh Rate | 60 Hz |
| Aspect Ratio | 16:9 |
| Brightness | 300 cd/m2 |
| Contrast | 4000:1 |
| Response Time | 6.5 ms |
| Viewing Angle (Horizontal / Vertical) | 178º / 178º |
| Color Depth | 8 bits, 16.7 M |
| Color Gamut | 68% NTSC |
| Operation | 24/7 |
| Inputs | HDMI 1.4 x1 VGA x1 |
| Outputs | Audio 3.5mm x1 |
| Speakers | 2x10 W |
| VESA | 200x200 mm |
| Average Power Consumption | <80 W |
| Power Supply | AC 100 ~ 240 V, 50/60 Hz |
| Dimensions | Without stand: 954.28 (W) ×561.6 (H) × 75.9 (D) mm With stand: 954.28 (W) × 616.21 (H) × 242.10 (D) mm |
| Weight | 7.5 Kg |
| Operating Conditions | Temperature: 0 ~ 50 ºC Humidity (non-condensing): 20 ~ 90 % |
| Storage Conditions | Temperature: -20 ~ 60 ºC Humidity (non-condensing): 5 ~ 90 % |
Package Contents
- Monitor
- Power Cable
- HDMI Cable
- Remote Control
- Stand
- User Manual
Use Case
The DS-D5043F3-1V0S monitor is an excellent choice for security installations in environments such as control centers and financial institutions. For instance, in a bank, this monitor can be used to display live feeds from multiple CCTV cameras, allowing security personnel to monitor activities in real-time. Its 24/7 operation capability ensures that surveillance is uninterrupted, providing peace of mind to both staff and customers. The high contrast ratio and FHD resolution enhance the clarity of images, making it easier to identify potential security threats. Additionally, the integrated speakers allow for audio alerts, further enhancing the monitoring experience. The monitor's compatibility with various video inputs ensures seamless integration into existing security systems, making it a versatile solution for any security setup.
Data sheet
- Brand
- HIKVISION
- Compatible models
- TVM-432,TVM-432,TVM-432,TVM-2355PT-B,TVM-2355PT-B,TVM-2355PT-B,SF-BRKT-TILT-32,SF-BRKT-TILT-32,SF-BRKT-FIX-32,SF-BRKT-FIX-32,SF-BRKT-CEILING-32,SF-BRKT-CEILING-32,SF-BRKT-ARM-32,SF-BRKT-ARM-32,SF-BRKT-ARM-32,PLB-CE1022-01,PLB-CE1022-01,LPA68-221,LPA68-221
Specific References
- EAN13
- 6936422113254
