The DS-2CD2D45G1/M-D/NF(2.8mm) is a high-performance IP camera designed for effective surveillance in various environments. With its 4 Megapixel resolution and advanced features, this device is ideal for both indoor and outdoor applications, ensuring clear and detailed images even in low-light conditions. The camera supports H.265+ compression, which optimizes bandwidth usage while maintaining high-quality video streams. Its compact design and 2.8 mm lens make it suitable for discreet installations in retail stores, offices, and residential areas.
| Brand | Hikvision |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Resolution | 4 Megapixel (2560x1440) |
| Main Stream Rate | 50 fps (2560x1440, 1920×1080, 1280×720) |
| Extra Stream Rate | 50 fps (640×480, 640×360, 320×240) |
| Third Stream Rate | 1 fps (1280×720, 640×480, 640×360, 320×240) |
| Compression | H.265+ / H.265 / H.264+ / H.264 |
| Lens | 2.8 mm |
| Field of View (FOV) | H: 98°, V: 53°, D: 115° |
| DORI | 62 m (D), 24.6 m (O), 12.4 m (R), 6.2 m (I) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum Illumination | Color 0.005 Lux @(F1.2, AGC ON) |
| Image Enhancements | WDR (120dB), 3D-NR, BLC, HLC, ROI, Mirror Function, Privacy Masking |
| Motion Detection | Yes |
| Internal Storage | Not available |
| Alarms | Not available |
| Audio | 1 input |
| Audio Type | Mono |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Network Interface | Ethernet 10/100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power Supply | DC 12 V / 130 mA / 1.5 W max. |
| Protection Grade | Indoor suitable |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | 31.5 mm (H) x 31.5 mm (W) x 49.6 mm (D) |
| Weight | 93 g |
The DS-2CD2D45G1/M-D/NF(2.8mm) is an excellent choice for small to medium-sized businesses looking to enhance their security measures. For instance, a retail store can deploy this mini IP camera at entry points and checkout areas to monitor customer activity and deter theft. With its remote monitoring capabilities via the Hik-Connect app, store owners can keep an eye on their premises from anywhere, ensuring peace of mind. The camera's WDR technology allows for clear images in varying lighting conditions, making it ideal for locations with both bright and dim areas. Additionally, the motion detection feature alerts users to any suspicious activity, enhancing overall security. The compact design allows for easy installation in tight spaces, making it a versatile solution for various environments.
