The DS-2DE3A404IWG-E is a high-performance IP PTZ camera designed for versatile surveillance applications. Ideal for both indoor and outdoor environments, this camera offers exceptional image quality and advanced features, making it suitable for security monitoring in various settings such as retail, parking lots, and public spaces. With its 4 Megapixel resolution and advanced low light capabilities, it ensures clear images even in challenging lighting conditions.
| Brand | HIKVISION |
| Series | VALUE |
| Image Sensor | 1/2.8“ Progressive Scan CMOS |
| Maximum Resolution | 4 Megapixel (2560x1440) |
| Optics | Varifocal lens 2.8~12 mm (4X optical zoom) |
| Field of View (FOV) | 96.7~31.6º (H), 51.1~17.7º (V), 115.1~36.3º (D) |
| DORI | Tele: 180 m (D), 71.4 m (O), 36 m (R), 18 m (I) |
| Main Stream Rate | 25 fps (2560x1440, 1920x1080, 1280x960, 1280x720) |
| Extra Stream Rate | 25 fps (704x576, 640x480, 352x288) |
| Third Stream Rate | 25 fps (1920x1080, 1280x960, 1280x720, 704x576, 640x480, 352x288) |
| Minimum Illumination | Color: 0.005 Lux @ (F1.5, AGC ON) 0 lux with IR range 50 m |
| Additional Deterrent Light | White light range 6 m |
| Compression | H.265+/ H.265 / H.264+/ H.264 |
| Bitrate | 32 Kbps ~16 Mbps |
| Digital Zoom | 16X |
| Electronic Shutter | 1/1s~1/30,000 s |
| Image Enhancements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, Privacy Masking, ROI |
| ANR | Yes |
| Motion Detection | Yes |
| Intelligent Features | AcuSense Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Entry Region, Exit Region Face Detection |
| Pan/Tilt Range | Horizontal: 0~350°, Vertical: 0°~90° |
| Manual Speed | Horizontal: 0.1~60 °/s, Vertical: 0.1~50 °/s |
| Speed Between Presets | Horizontal: 60 °/s, Vertical: 60 °/s |
| Preset Positions | 300 presets, 4 auto patterns, 8 auto tours, auto pan, auto scan |
| Internal Storage | MicroSD card slot up to 256 GB |
| Audio | 1 input (Line In) / 1 output (Line Out) Integrated microphone and speaker |
| Audio Compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps (MP2L2) |
| Alarms | 1 Input / 1 Output |
| PTZ Control | Via network access |
| Network Interface | Ethernet 10 / 100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF, ISAPI, SDK, ISUP |
| Power Supply | DC 12 V / 3.33 A / 14 W max. PoE+ IEEE802.3at |
| Operating Temperature | -30º C ~ +65º C |
| Material | ADC12 + PC |
| Protection Rating | IP66 / 6000 V surge protection |
| Dimensions (without mount) | 182 mm (H) x 120.5 mm (W) x 179.3 mm (D) |
| Weight (without mount) | 1125 g |
The DS-2DE3A404IWG-E is an excellent choice for comprehensive surveillance in various environments, such as shopping malls, schools, and parking lots. With its 4 Megapixel resolution and IR capabilities, it provides clear images day and night, ensuring effective monitoring. The camera's AcuSense technology significantly reduces false alarms by accurately distinguishing between humans and vehicles, making it ideal for busy public areas. Additionally, the remote access feature allows users to monitor live feeds from anywhere using a smartphone or web browser, enhancing security management. The camera's robust IP66 waterproof rating ensures durability in outdoor settings, while the integrated microphone and speaker facilitate two-way audio communication, adding another layer of security. Overall, the DS-2DE3A404IWG-E is a versatile solution for those seeking reliable and advanced surveillance technology.
