- Hikvision
- PRO Series IP Dome Camera
- 4 Megapixel Resolution (2688x1520)
- 2.8 mm Lens | Alarms | Audio | PoE
- IR Range 30 m | Motion Detection 2.0
- AcuSense | Face Detection
Description & Key Features: DS-2CD2143G2-IS(2.8mm)
The DS-2CD2143G2-IS(2.8mm) is a high-performance IP dome camera designed for versatile surveillance applications. Ideal for both indoor and outdoor environments, this camera offers exceptional image quality with its 4 Megapixel resolution and advanced features such as motion detection and face detection. With its robust design, it is suitable for various security needs, ensuring reliable monitoring in critical areas.
- Hikvision
- PRO Series
- IP Dome Camera
- 1/3" Progressive Scan CMOS
- 4 Megapixel (2688x1520)
- 2.8 mm Lens
- 0 Lux
- IR Range 30 m
- H.265+ / H.265 / H.264+ / H.264 Compression
- Motion Detection 2.0
- AcuSense, false alarm filter for vehicles and people (line crossing and area intrusion)
- Face Detection
- WDR (120 dB)
- 3D-DNR
- Alarms
- Audio
- MicroSD card slot up to 256 GB
- WEB, CMS, Smartphone, and NVR interface
- ONVIF compatible
- PoE (IEEE802.3af)
- IP67 Waterproof
- IK10 Vandal Resistant
Specifications: DS-2CD2143G2-IS(2.8mm)
| Brand | HIKVISION |
| Series | PRO |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Maximum Resolution | 4 Megapixel (2688x1520) |
| Main Stream Rate | 25 fps (2688x1520, 1920×1080, 1280×720) |
| Extra Stream Rate | 25 fps (640x480, 640×360) |
| Third Stream Rate | 10 fps (1920×1080, 1280×720, 640x480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Optics | 2.8 mm |
| Field of View (FOV) | H: 103°, V: 55°, D: 122° |
| DORI | 67 m (D), 26 m (O), 13 m (R), 6 m (I) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum Illumination | Color: 0.005 Lux @(F1.6, AGC ON) 0 Lux with IR range 30 m |
| Day/Night | Removable ICR mechanical filter |
| Image Enhancements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror function, Privacy masking |
| ANR | Yes |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. * Motion detection and AcuSense cannot be enabled simultaneously on the same device. |
| Intelligent Functions | AcuSense Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion * Motion detection and AcuSense cannot be enabled simultaneously on the same device. |
| Face Detection | Yes |
| Internal Storage | MicroSD card slot up to 256 GB |
| Alarms | 1 input / 1 relay |
| Audio | 1 input / 1 output |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio Bit Rate | 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/16Kbps-64Kbps(AAC)/32-192Kbps(MP2L2)/8-320Kbps(MP3) |
| Network Interface | Ethernet 10 / 100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power Supply | DC 12 V / 400 mA / 5 W max. / PoE IEEE802.3af |
| Protection Grade | IP67 Waterproof, IK10 Vandal Resistant |
| Material | Body: Aluminum Alloy Dome: Plastic |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | Ø 110.8 mm x 84.7 mm (H) |
| Base Dimensions | Ø base 110.8 mm / Ø between screws 100.4 mm / 3 screws |
| Weight | 530 g |
Package Contents
- Hikvision IP Dome Camera
- Installation Materials
- User Manual
Use Case
The DS-2CD2143G2-IS(2.8mm) is perfect for a variety of surveillance scenarios, such as monitoring retail stores, parking lots, or office buildings. With its high-resolution imaging and night vision capabilities, this camera ensures clear visibility even in low-light conditions. Installers can benefit from its plug-and-play setup, allowing for quick deployment and integration into existing security systems. The remote monitoring feature enables users to access live feeds via smartphones or web browsers, enhancing security management. Additionally, the AcuSense technology significantly reduces false alarms by accurately distinguishing between humans and vehicles, making it an ideal choice for busy environments. Overall, the DS-2CD2143G2-IS(2.8mm) combines advanced technology with user-friendly features, providing a reliable solution for comprehensive surveillance needs.
Data sheet
- Brand
- HIKVISION PRO
- Resolution
- 4 Mpx
- WDR
- WDR (120 dB)
- IR Distance
- 30 m
- Audio
- 1 Entrada / 1 Salida
- SD Slot
- Ranura MicroSD hasta 256 GB
- Wi-Fi
- No dispone
- IP Rating
- IP67
- IK Rating
- IK10
- Series
- PRO
- POE
- PoE (IEEE802.3af)
- Lens
- 2.8 mm
- Compatible models
- DS-1280ZJ-DM18,DS-1280ZJ-DM18,DS-1276ZJ-SUS,DS-1276ZJ-SUS,DS-1275ZJ-SUS,DS-1275ZJ-SUS,DS-1272ZJ-110B,DS-1272ZJ-110B,DS-1272ZJ-110,DS-1272ZJ-110,DS-1271ZJ-110,DS-1271ZJ-110,DS-1259ZJ,DS-1259ZJ,DS-1258ZJ,DS-1258ZJ,DS-1250ZJ,DS-1250ZJ
Specific References
- EAN13
- 6941264070870
