- Value Range Bullet IP Camera
- Resolution 8 MP (4256x1888)
- Dual Lens 2 mm Panoramic View
- Hybrid Light Range 30 m
- Integrated Microphone | Deterrent Siren and Flash
- Motion Detection 2.0 | MicroSD | PoE | IP67
Description & Key Features: DS-2CD1T83G2P-LIUF/SL(2mm)
The DS-2CD1T83G2P-LIUF/SL is a high-performance IP bullet camera designed for comprehensive surveillance solutions. Ideal for both residential and commercial applications, this camera provides a 180-degree panoramic view with its dual 2 mm lens, ensuring extensive coverage of large areas. With features such as motion detection and integrated audio capabilities, it enhances security monitoring while offering flexibility in deployment.
- Hikvision
- Value Series
- IP Bullet Camera
- 1/2.4" Progressive Scan CMOS
- 8 Megapixel (4256x1888)
- Dual Lens 2 mm
- 180º Panoramic View
- 0 Lux
- Hybrid Light: IR and White Light
- Hybrid Light Range 30 m
- Compression H.265+ / H.265 / H.264+ / H.264
- Motion Detection 2.0
- WDR (120 dB)
- 3D-DNR
- Integrated Microphone and Speaker
- Integrated Disruptive Siren and White Light Flash
- MicroSD Slot up to 512 GB
- WEB, CMS, Smartphone, and NVR Interface
- ONVIF Compatible
- PoE (IEEE802.3af)
- IP67 Waterproof
Specifications: DS-2CD1T83G2P-LIUF/SL(2mm)
| Brand | HIKVISION |
| Series | Value |
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Maximum Resolution | 8 Megapixel (4256x1888) |
| Main Stream Rate | 20 fps (4256x1888) |
| Extra Stream Rate | 20 fps (1200x536, 960x432) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Optics | Dual Lens 2 mm |
| Field of View (FOV) | H: 180°, V: 77° |
| DORI | 50 m (D), 20 m (O), 10 m (R), 5 m (I) |
| Electronic Shutter | 1~1/100,000 s |
| Minimum Illumination | Color: 0.005 Lux @(F1.6, AGC ON) 0 Lux with IR range 30 m |
| Supplementary Lighting | Hybrid Light: IR range 30 m White light range 30 m |
| Day/Night | Removable ICR Mechanical Filter |
| Image Enhancements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Privacy Masking |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. |
| Audio | Integrated Microphone and Speaker |
| Disruptive Alarm | Integrated siren and white light flash in the camera |
| Internal Storage | MicroSD card slot up to 512 GB |
| Audio Type | Mono |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bitrate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Network Interface | 1 RJ45 Ethernet 10 M/100 M self-adaptive |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF (Profile S, T, G), ISAPI, SDK |
| Power Supply | DC 12 V / 830 mA / 10 W max. PoE IEEE802.3af |
| Protection Grade | IP67 Waterproof |
| Material | Metal and Plastic |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | 103.6 mm (W) x 76 mm (H) x 234.5 mm (D) |
| Weight | 835 g |
Package Contents
- Hikvision Value IP Bullet Camera
- Installation Material
- User Manual
Use Case
The DS-2CD1T83G2P-LIUF/SL camera is perfect for a variety of surveillance scenarios, such as monitoring large retail spaces or outdoor areas. With its 180-degree panoramic view, it can effectively cover wide areas, reducing the number of cameras needed for comprehensive security. The integrated microphone and speaker allow for two-way audio communication, enhancing interaction with visitors or potential intruders. Additionally, the motion detection 2.0 feature provides advanced alerts, classifying detected movements as human or vehicle, which is crucial for targeted security responses. The camera's IP67 waterproof rating ensures reliable performance in various weather conditions, making it suitable for outdoor installations. Furthermore, the remote access capabilities via web browsers and mobile apps enable users to monitor their premises from anywhere, ensuring peace of mind.
Data sheet
- Brand
- HIKVISION
- Resolution
- 8 Mpx
- Technology
- IP
- WDR
- WDR (120 dB)
- IR Distance
- 30 m
- Audio
- Micrófono / Altavoz disuasorio
- SD Slot
- Ranura MicroSD hasta 512 GB
- Wi-Fi
- No dispone
- IP Rating
- IP67
- IK Rating
- No dispone
- Series
- VALUE
- POE
- PoE (IEEE802.3af)
- Lens
- 2.8 mm
- Compatible models
- DS-1280ZJ-XS,DS-1280ZJ-XS
Specific References
- EAN13
- 6936422121396
