| Brand | Hikvision |
| Range | Value |
| Image sensor | 5Mpx CMOS |
| Maximum resolution | 5 Megapixel (2560x1944) at 20 fps |
| Resolution | TVI: 5Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps) |
| Lens | 2.8 mm |
| Angle of view (FOV) | 85º (H), 63º (V), 110º (D) |
| Minimum illumination | 0.01 Lux @ (F2.0, AGC ON) |
| Infrared illumination | 0 Lux / (Smart IR range 40 m) |
| Day / Night | Auto / Color / White and black (ICR) |
| Video output | 1 x BNC HDTVI |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, BLC, HLC, 2DNR, AGC, AWB, Smart IR |
| Communication | HIKVISION-C |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 3 W max. PoC.af (power over coaxial cable) |
| Protection degree | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Body: Metal Cover: Plastic |
| Dimensions | Ø 109.82 mm x 91 (H) mm |
| Base diameter | base Ø 109.82 mm / Ø between screws 85 mm / 3 screws |
| Weight | 326 g |
Data sheet
