An access controller is a professional element for perimeter and door protection. It is located in secure and hidden places, allowing the connection of readers, which are positioned in visible locations of the installation to identify the user seeking access, as well as the connection to electronic locks, which will be activated if the user is permitted access.
This controller supports readers based on the Wiegand protocol, allowing direct wiring from each reader to the controller. It features 2 readers for entry and exit at each door and supports biometric readers, which connect via RS485 and allow cascading BUS connections. By supporting RS485, it also supports OSDP on the same connector, with the latter being customizable in configuration and allowing up to 2 readers through this method.
This model includes 1 relay output, configurable as a dry contact (no voltage) or wet contact (with voltage).
By using an access controller, it is possible to secure certain functions such as opening all doors upon receiving a fire signal or activating an alarm upon detecting a forced door. Thanks to its inputs and outputs, managing these functions becomes simpler.
Advanced configurable functions: anti-passback technology (prevents a person from passing if they are already inside), turnstiles (a double-door system that allows one person to pass at a time), or occupancy control (prevents access to more users once a certain number is exceeded).
User configuration, schedules, and access groups, as well as special functions, relay opening times, or reader reading times, are managed through the iVMS-4200 software.
| Brand | Hikvision |
| Model | DS-K2621X(P) |
| Hardware CPU | RAM: 128 MB | ROM: 4 GB |
| Capacity | Up to 100,000 users (97,000 users / 3,000 visitors / 5,000 fingerprints) |
| Records | 300,000 records |
| Identification Modes | Facial, fingerprint, card, QR, and/or passwords |
| Proximity Card | RFID EM 125 kHz and MF 13.56 MHz |
| Communication | TCP/IP, ISAPI, and ISUP |
| Outputs | 1 x relay output, 2 x alarm outputs |
| Inputs | 2 x Wiegand 26/34, 2 x RS485/OSDP, 1 x door sensor, 1 x opening button, 2 x alarm inputs, 1 x tamper |
| Software | iVMS-4200 / iVMS-4200 AC |
| Mobile Application | Hik-Connect |
| Functions | Multi-door turnstiles, anti-passback, multi-card, first card opening |
| Power Supply | DC 12 V / 1 A max. |
| Operating Temperature | -10 ºC ~ +55 ºC |
| Dimensions | 160 (W) x 205 (H) x 25 (D) mm |
| Weight | 500 g |
