| Brand | X-Security |
| Range | Lite |
| Image Sensor | 4K CMOS |
| Maximum Resolution | CVI: 4K@15 fps; 5M@25 fps; 4M@30 fps; 1080p@30 fps AHD: 4K@15 fps TVI: 4K@15 fps CVBS: 960H |
| Video Output | 1 x BNC CVI/TVI/AHD/CVBS |
| Optics | 3.6 mm |
| Day/Night | Removable ICR mechanical filter |
| Minimum Illumination | 0.005 Lux (Color), 0 Lux (IR On) |
| Lighting Range | Intelligent dual lighting: IR up to 40 m White LED up to 40 m (Turns on when there is a target in range) |
| Basic Functions | OSD Menu, Day/Night with IR-CUT (ICR) |
| Configurable OSD Functions | WDR 120 dB, Smart IR, AWB, AGC, BLC, HLC, 3DNR |
| Audio | Integrated microphone |
| Power | DC 12 V / 5.7 W max. |
| Protection Grade | IP67 Waterproof |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | 198.4×80.2×76.2 mm |
| Weight | 480 g |
