| Brand | Hikvision |
| Range | Value |
| IP Camera Inputs | 4-port PoE IEEE802.3af/at Switch (max. 36 W) |
| PoE Power | 4 (Max. 36W) |
| Compatible IP Cameras | HIKVISION (native protocol), ONVIF |
| Video Outputs | 1xHDMI FullHD |
| Video Compression Format | H.265+ / H.265 / H.264+ / H.264 |
| Display Resolution | HDMI: 1920x1080, 1600x1200, 1280x1024, 1280x720 |
| Total Bandwidth | 40 Mbps input / 60 Mbps output |
| Stream Type | Video / Video + Audio |
| Main Stream Recording | 4MP / 3MP/ 1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Decoding Capacity | 2CH@4MPx, 4CH@1080p |
| Simultaneous Function | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms | Not available |
| Recording Method | Manual, scheduled, motion detection |
| External Backup | USB Memory / USB HDD / CD-RW USB / DVR-RW USB |
| Remote Access | Web Browser, Hik-Connect Smartphone App, iVMS-4200 PC Software, and Hik-Central |
| Remote Connections | 128 |
| Internal Storage | 1 TB SSD (included) |
| Communication | 2 x USB 2.0 (Back) / 1 x RJ45 10/100M (Ethernet) |
| Power | DC 48 V / 1.04 A, ≤ 10 W (without HDD) |
| Operating Temperature | -10ºC ~ 45ºC (10%-90% Humidity) |
| Dimensions / Weight | 27 (H) x 160 (W) x 112 (D) mm / 0.5 Kg (without HDD) |
Data sheet
