- Motorized Ranger Mini 3MP Camera
- WiFi 6
- 3.6 mm lens / Auto-tracking / IR + Smart Color
- Two-way audio / Siren
- PIR sensor / Human detection
- Mini form factor - Indoor/Outdoor
Why choose the Imou Ranger Mini 3MP WiFi 6 Motorized Camera IPC-K2MP-3H1WE for your security?
The Imou Ranger Mini 3MP delivers professional-level perimeter and indoor surveillance in a compact, user-installable package. Set up quickly via the Imou Life app and access live, two-way audio/video from your smartphone. High-resolution 3MP imaging, motorized pan/tilt and automatic tracking eliminate blind spots and give continuous coverage of moving subjects. Human detection combined with a PIR motion sensor and built-in siren prioritizes genuine threats and sharply reduces false alerts, so you are notified only when action is required. Weatherproof IP66 construction and a small form factor allow flexible installation outdoors or indoors, maintaining reliable operation in demanding environmental conditions.
Key features and technological advantages
- WiFi 6 connectivity and stable, DIY-ready setup: supports WiFi 6 on 2.4 GHz and 10/100 Ethernet (RJ45) to ensure smooth, low-latency video streaming even on congested networks. Simple step-by-step installation through the Imou Life app enables fast deployment without a professional installer while preserving enterprise-grade reliability for home or small business environments.
- 3MP video with color night vision and deterrence mode: 2304 x 1296 resolution produces clear images to identify faces and fine details. Infrared illumination extends effective night range to 10 meters, while Color Night Vision and an integrated dissuasive flash provide color images at night and serve as an immediate visual deterrent when suspicious activity is detected.
- Motorized autotracking and intelligent human detection: remote Pan/Tilt control (355° horizontal, 5°–50° vertical) combined with motion-tracking follows moving subjects across the scene to minimize blind spots. Dedicated human detection algorithms plus a PIR sensor filter out common false triggers (pets, shadows, lighting changes), increasing alert accuracy and reducing unnecessary notifications.
- Two-way audio, integrated siren and flexible recording options: built-in microphone and speaker enable real-time communication to manage visitors, personnel or to verbally deter intruders. The onboard siren adds an audible security layer. Store footage locally on microSD (up to 512 GB), to Imou/Dahua NVRs via proprietary protocol, to third-party NVRs over ONVIF, or to the Imou Protect cloud (subscription), allowing you to tailor retention and redundancy to your security policy.
Product specifications IPC-K2MP-3H1WE-IMOU
| Brand | Imou |
| Model | IPC-K2MP-3H1WE-IMOU / Ranger Mini 3MP |
| Image sensor | 1/3” Progressive Scan CMOS (designed for improved sensitivity and image clarity in varied lighting) |
| Main stream encoding | 2304 x 1296 (3MP) — high-resolution stream suitable for identification and forensic review |
| Lens | 3.6 mm (Diagonal field of view 79°) — balanced FOV for coverage and identificatory detail |
| Pan/Tilt movement (remote) | Horizontal: 355°; Vertical: 5°–50° — enables near-full horizontal sweep and vertical adjustment to track activity across wide areas |
| Tracking modes | Motion-tracking (movement) — automated subject following to maintain continuous observation |
| Infrared illumination | 0 lux IR LEDs (10 m) — reliable monochrome night vision up to 10 meters |
| Color illumination | Color Night Vision / Dissuasion flash — retains color detail at night and provides active visual deterrence |
| Audio | Two-way audio (microphone and speaker) — enables live interaction and remote deterrence |
| Detection types | Video motion detection Intelligent human detection — prioritizes human targets to reduce false alarms |
| Local storage | Supports microSD card (max. 512 GB) — local, high-capacity recording for continuous or event-based capture |
| External storage | Imou or Dahua NVRs via proprietary protocol Third-party NVRs via ONVIF Cloud recording through Imou Protect (subscription) — flexible, multi-tier storage and backup options |
| Network interface | WiFi 6 2.4 GHz IEEE 802.11 b/g/n (supports improved throughput and device density) Ethernet 10/100 Base-T (RJ45) |
| Remote access | Smartphone app: Imou Life PC software: Imou PC No web browser access available — mobile and desktop apps provide secure remote monitoring and management |
| Power | DC 5 V / 1000 mA Type-C — standard low-voltage power for safe, flexible installations |
| Ingress protection | IP66 waterproof — suitable for exposed outdoor locations and resistant to heavy rain and dust |
| Operating temperature | -30°C ~ +60°C — maintains performance across wide temperature ranges |
| Dimensions | 95 mm x 96 mm x 109 mm — compact footprint for discreet placement |
| Weight | 200 g |
Package contents
- WiFi camera
- Power adapter
- Installation hardware
- Quick start guide
Data sheet
- Brand
- IMOU
- Type of camera
- PTZ
- Resolution
- 3 Mpx
- IR Distance
- IR 10 m
- Audio
- Mic + Altavoz + Sirena
- Wi-Fi
- WiFi
- Indoor / Outdoor
- Outdoor
- Product type
- IP Cam - Motorizada Exterior
- Connectivity
- WiFi 2.4GHz + LAN RJ45
- AI Detection
- Movimiento + Humanos
Specific References
- EAN13
- 6971927236275
