Hikvision DS-K1T502DBWX-CQR IP65 IK09 Access Control Terminal with Camera and MIFARE DESFire Card Reader

An autonomous access control device consists of the combination of a controller and a reader in a single unit: it is capable of identifying users, making the decision of whether they have permission to access the facility, and operating the electronic lock through its relay.

This device allows identification through MF 13.56 MHz and MF DESFire 13.56 MHz cards or key fobs, QR code reading, as well as a keypad for numeric codes.

Advanced configurable functions: operates as a video intercom.

Its IP65 outdoor rating allows for installation in exposed environments. Additionally, its IK09 vandal-resistant rating enables it to withstand more challenging environments.

User configuration, schedules, and access groups, as well as special functions, relay opening times, or reader reading times, are managed from the iVMS-4200 software.

• Hikvision
• Standalone access control reader
• Identification via MF DESFire card, QR, Bluetooth (supported only with HikCentral and HikConnect Teams), password and/or combinations
• Capacity for 100,000 cards and 300,000 records
• Communication via TCP/IP, WiFi, RS485, and Wiegand
• Integrated controller (door sensor, button, and relay)
• Integrated camera, speaker, and microphone
• Remote openings via Hik-Connect
• Compatible with iVMS-4200 software
• Suitable for outdoor use IP65
• Vandal-resistant IK09

Specifications: DS-K1T502DBWX-CQR

Package Contents

• Hikvision access control device
• Mounting materials
• User instructions
