| Brand | HIKVISION |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 4 Megapixel (2560x1440) |
| Main Stream Rate | 12.5 fps (2560x1440, 1920×1080, 1280×720) |
| Sub Stream Rate | 12.5 fps (1280×720, 640x480, 640x360) |
| Compression | H.265/H.264 |
| Min. Illumination | Color: 0.005 Lux @(F1.6, AGC ON) 0 Lux with IR range 30 m |
| Day/Night | Removable ICR mechanical filter |
| Lens | 2.8 mm |
| Field of View (FOV) | H: 94°, V: 49°, D: 114° |
| DORI | 68 m (D), 27 m (O), 13 m (R), 6 m (I) |
| Video Bit Rate | 32 Kbps~8 Mbps |
| Image Enhancement | DWDR, BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror effect |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied to motion detection. |
| Pan/Tilt Range | Horizontal: 0~360° Vertical: -60~0° |
| Manual Speed | Up to 25 °/s Up to 25 °/s |
| Audio | Built-in microphone Built-in speaker |
| Transducer | Integrated: PIR + radar |
| Communication Interface | 4G Nano SIM (LTE-FDD, LTE-TDD, UMTS) |
| Internal Storage | Micro SD card slot up to 512 GB |
| Remote Access | Web Browser, Hik-Connect Smartphone App, iVMS-4200 and Hik-Central PC Software |
| Power Supply | DC 12 V ± 25% Power interface: four-core aviation connector |
| Solar Panel | 20 W |
| Protection Grade | IP66 Waterproof |
| Battery Capacity | 90 Wh |
| Battery Life Cycle | 48 hours (1.85 W) (Battery life on full charge without solar input) |
