The iDS-6704HUHI-M is a versatile encoder for analog cameras designed to enhance video surveillance systems. It is ideal for both residential and commercial applications, providing seamless integration with existing setups. This device supports multiple video formats, including HDTVI, HDCVI, AHD, and CVBS, making it a flexible choice for various environments. With advanced features like AcuSense technology, it minimizes false alarms, ensuring reliable monitoring.
| Brand | HIKVISION |
| Series | PRO |
| Video Format | TVI / CVI / AHD / CVBS / IP |
| Analog Camera Inputs | 4 CH |
| Hybrid Configuration | 2 CH additional IP: Up to 6 IP channels (8 Mpx), replacing all BNC channels |
| Video Outputs | 1 BNC CVBS (1.0 Vp-p 75 Ω) Resolution: PAL: 704 × 576, / NTSC: 704 × 480 |
| Bitrate | 32 Kbps ~ 10 Mbps |
| Two-way Audio | 4 inputs / 1 RCA output |
| Audio Inputs | 4 RCA Channels |
| Audio Outputs | 1 RCA Channel |
| Audio Bit Rate | 64 kbps |
| Audio Compression | G.711u |
| Video Decoding Format | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Input Resolution | HDTVI: 8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps * 8 Mpx signal only available for channel 1 HDCVI: 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps AHD: 5 MP, 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps CVBS: PAL/NTSC |
| Main Stream Encoding | 8Mpx @8 fps / 5Mpx @12 fps / 4 Mpx @15 fps / 8 Mpx Lite @15 fps / 3 Mpx @18 fps / 1080p, 720p, WD1, 4CIF, VGA, CIF @25 fps *8 Mpx @ 8 fps only available for channel 1. 8 Mpx Lite only available for channels 2 to 4 |
| Extra Stream Encoding | WD1, 4CIF, CIF @ 25 fps |
| Video Bit Rate | 32 Kbps~10 Mbps |
| Dual Stream | Yes |
| Alarms | 4 inputs / 1 output |
| Artificial Intelligence | AcuSense: Perimeter protection based on VCA rules with false alarm filter for human and vehicle detection applied on: Line Crossing and Area Intrusion. |
| Communication | RS-485 |
| Network Interface | 1 x RJ45 10/100M |
| Internal Storage | 1 SATA 3.5" HDD up to 10 TB (not included) |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Compatible IP Cameras | Hikvision, ONVIF |
| Power Supply | DC 12 V, 1.5 A, 10 W max. (without HDD) |
| Operating Temperature | -10º C ~ +55º C |
| Dimensions / Weight | 45 mm (H) x 315 mm (W) x 242 mm (D) |
| Weight | 1.16 Kg (without HDD) |
The iDS-6704HUHI-M encoder is perfect for a variety of surveillance scenarios, particularly in retail environments where monitoring customer behavior and securing assets is crucial. By integrating this device, installers can easily connect up to 4 analog cameras while also adding 2 additional IP channels, allowing for a hybrid setup that maximizes coverage. The AcuSense technology significantly reduces false alarms, ensuring that security personnel can focus on real threats. Furthermore, the device supports remote monitoring via web browsers and mobile applications, providing flexibility for users to access live feeds from anywhere. This encoder's compatibility with ONVIF ensures seamless integration with existing systems, making it a reliable choice for enhancing security measures in any facility.
