| Video Format |
HDCVI / CVBS PAL / IP |
| Video Inputs |
8 BNC Channels |
| IP Inputs |
Up to 8 Channels |
| Video Outputs |
2 HDMI Full HD, 1 VGA, 1 BNC |
| Audio Inputs |
4 BNC Channels |
| Audio Outputs |
1 BNC Channel |
| Bidirectional Audio |
1 MIC IN BNC Channel / 1 MIC OUT BNC Channel |
| Video/Audio Compression |
H.264 / G.711 |
| Display Resolution |
1920x1080, 1280x1024, 1280x720, 1024x768, 800x600 |
| Recording Resolution |
1920x1080(1080P), 1280x720(720P), 960x576(960H WD1), 704x576(D1) |
| Main Stream Recording |
Channel 1~8: 1080P/720P/960H WD1/D1/2CIF/CIF/QCIF (1~25 FPS) |
| Extra Stream Recording |
Channel 1~8: CIF/QCIF (1~25 FPS) |
| Image Quality |
6 configurable levels |
| Simultaneous Function |
Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms |
8 inputs / 6 relay NO/NC |
| Recording Method |
Manual, scheduled, motion detection, alarm |
| Backup |
USB (Memory, HDD, CD-RW, DVD-RW) / eSATA / CD/DVD-RW / Network |
| Internal Storage |
4 SATA 3.5" HDD up to 4 TB each or 3 HDD and 1 CD/DVD-RW (not included) |
| Communication |
RS485 (PTZ) / RS232 / RS422 / 3 x USB (Mouse and backup) / RJ45 (Ethernet) |
| Remote Access |
Browser (ActiveX), Mobile App, or PSS Software |
| Power Supply |
AC 100~240 V, 50/60 Hz |
| Dimensions / Weight |
70 (H) x 440 (W) x 410 (D) mm / 6.0 Kg |
