Multitransmitter via radio AJ-MULTITRANSMITTER-B

Name: Multitransmitter via radio AJ-MULTITRANSMITTER-B
Brand: AJAX
Price: 139.669421 EUR
Availability: OutOfStock

Brand: AJAX

SKU: AJ-MULTITRANSMITTER-B

Condition: New product

Rating: Sign in to write a review

Overview

Radio multitransmitter AJ-MULTITRANSMITTER-B

Ajax
Multi-input radio transmitter
Wireless 868 MHz Jeweler
Bidirectional
Internal antenna free space range 2000 m
18 wired alarm and anti-sabotage tamper inputs
Inhibition detection
Tamper anti-opening
Double power output 12 V / 1 A
220 VAC power supply and 4 or 7 Ah backup battery (not included)
Compatibility with third-party detectors with wired alarm output and with all Ajax Hubs

Brand	Ajax
Frequency	868 MHz Jeweler
Transmission distance	≤ 2000 m in open space
Detection anti-inhibition	Available
Wired inputs	Up to 18 (alarm or tamper)
Alarm inputs	NO/NC or end of line resistance REOL (NO/NC) / Pulse or bistable
End of line resistance EOL	From 1 kΩ to 7.5 kΩ
Input tamper	NC: Normally Closed
Anti-opening tamper	Front and rear
Power output	Two 12 V outputs / 1 A (total) for wired detectors
Compatibility	Compatible with Ajax Hub, Hub Plus, Hub 2, Hub 2 Plus and ReX
Power	AC 110~250 V, 50/60 Hz
Backup battery	12 V / 4 or 7 Ah battery (not included)
Functions advanced	KeyArm Zone (key zone)
Temp. operation	-10 ºC ~ 40 ºC
Backup battery dimensions	150 (H) x 64 (W) x 94 (D) mm
Dimensions	196 (H) x 238 (W) x 100 (D) mm
