| Brand | Ajax |
| Frequency | 868 MHz Jeweler |
| Transmission distance | ≤ 2000 m in open space |
| Detection anti-inhibition | Available |
| Wired inputs | Up to 18 (alarm or tamper) |
| Alarm inputs | NO/NC or end of line resistance REOL (NO/NC) / Pulse or bistable |
| End of line resistance EOL | From 1 kΩ to 7.5 kΩ |
| Input tamper | NC: Normally Closed |
| Anti-opening tamper | Front and rear |
| Power output | Two 12 V outputs / 1 A (total) for wired detectors |
| Compatibility | Compatible with Ajax Hub, Hub Plus, Hub 2, Hub 2 Plus and ReX |
| Power | AC 110~250 V, 50/60 Hz |
| Backup battery | 12 V / 4 or 7 Ah battery (not included) |
| Functions advanced | KeyArm Zone (key zone) |
| Temp. operation | -10 ºC ~ 40 ºC |
| Backup battery dimensions | 150 (H) x 64 (W) x 94 (D) mm |
| Dimensions | 196 (H) x 238 (W) x 100 (D) mm |
